PDF Image and Text Nodes Windows Files Tutorial

PDF Image and Text Nodes Windows Files Tutorial

We turn our attention, further to the progress of the recent PDF Image and Text Nodes Image Undo Tutorial, to …

  • Windows (via a Windows MAMP scenario) browsing for files … as distinct from …
  • macOS (via a macOS MAMP scenario) browsing for files

Why? Well, the Windows directory separator (ie. \ backslash) being different to the macOS (and Linux) directory separator (ie. / forward slash) can cause issues, and it being “files” we are talking about, it will be a serverside (PHP, in our case) issue.

Yes, there is a PHP DIRECTORY_SEPARATOR constant we try to use as much as possible, but a Windows platform is not our “go to” testing platform. That’s our excuse …

… and we’re sticking to it!

But are you one of those people who takes a while, but eventually feels guilt about not attending to “this platform” or “that web browser” as far as functionality goes? Possibly a better system than ours, though, would be to write this down as a “thing to do”, rather than relying on guilt!

Also, today, we’ve added onto those image annotation menus a “u” option for the Undo functionality of the recent PDF Image and Text Nodes Image Undo Tutorial in our changed pdfimageplustext.php Image and Text PDF creator PHP web application (helped out by the changed find_images_via_size.php (we’d now like you to download to MAMP Document Root PHP folder) web application).

Previous relevant PDF Image and Text Nodes Image Undo Tutorial is shown below.

PDF Image and Text Nodes Image Undo Tutorial

PDF Image and Text Nodes Image Undo Tutorial

Several blog postings lately, up to yesterday’s PDF Image and Text Nodes Image Transformations Tutorial and today’s tutorial have been shoring up …

  • the Image “backdrop” functionality to our PDF Image and Text Nodes PDF Creator PHP web application of recent times … supplementing …
  • the Text node functionality, which featured Undo functionality described in Image and Text PDF Undo Emoji Tutorial

… and it is one of today’s tasks to …

  • add Image “backdrop” functionality Undo functionality …
    <?php

    echo "<!doctype html><html><body onload=\" if (parent.document.getElementById('slideshow')) { parent.document.getElementById('slideshow').value=parent.undobackup('" . datauriit($qpzm) . "'); parent.forcescale(); } \"></body></html>";

    ?>
    … PHP change with Javascript …
    <?php echo ”

    var awobackup='';

    function undobackup(newc) {
    awobackup=document.getElementById('slideshow').value;
    document.getElementById('redoopt').style.display='block';
    return newc;
    }

    function zoomsame(tv) {
    if (tv.trim() != '') {
    if (tv.trim().toLowerCase() == 'redo') {
    redo();
    } else     if (tv.trim().toLowerCase() == 'rotation') {
    rotateim(eval(document.getElementById('rotation').value));
    document.getElementById('sfilter').value='';
    } else {
    //document.getElementById('rotation').value=document.getElementById('trot').value;
    document.getElementById('dudata').value=document.getElementById('slideshow').value;
    document.getElementById('dudata').name=tv;
    //alert(1);
    document.getElementById('oneform').submit(); // document.getElementById('isone').click();
    //alert(11);
    }
    }
    }

    function redo() {
    if (awobackup != '') {
    //alert('will do');
    mycanvas = document.getElementById('canvas');
    ctx = mycanvas.getContext('2d');
    myimg = new Image;
    myimg.onload = function() {
    var ow=myimg.width;
    var oh=myimg.height;
    mycanvas.width=eval(myimg.width);
    mycanvas.height=eval(myimg.height);
    mycanvas.style.width='' + eval(myimg.width) + 'px';
    mycanvas.style.height='' + eval(myimg.height) + 'px';
    if (document.getElementById('tsiz')) {
    ctx.font = '' + document.getElementById('tsiz').value.trim() + 'px ' + document.getElementById('tfam').value.trim();
    }
    if (document.getElementById('tcol')) {
    ctx.fillStyle='' + document.getElementById('tcol').value.trim();
    }
    ctx.drawImage(myimg,0,0,ow,oh,0,0,mycanvas.width,mycanvas.height); // Or at whatever offset you like
    //alert(564);
    awonow=mycanvas.toDataURL('image/jpeg');
    sofarso=sofarso.replace(awowatchsofar, awonow);
    awowatchsofar=awonow;
    datauri=awonow;
    if (actualuri == '') { actualuri=datauri; }
    datauris[0]=datauri;
    document.getElementById('slideshow').value=awonow;
    document.body.style.backgroundImage='url(' + awonow + ')';
    if (document.getElementById('inimg')) {
    document.getElementById('inimg').style.width='' + eval(mycanvas.width * towhat / curfactor) + 'px';
    document.getElementById('inimg').style.height='' + eval(mycanvas.height * towhat / curfactor) + 'px';
    document.getElementById('inimg').width=eval(mycanvas.width * towhat / curfactor);
    document.getElementById('inimg').height=eval(mycanvas.height * towhat / curfactor);
    document.getElementById('inimg').src=awonow;
    }
    document.getElementById('dimap').innerHTML=\"<img id=imimg style='z-index:99;visibility:visible;position:absolute;top:0px;left:0px;' src='\" + datauri + \"' width='\" + mycanvas.width + \"' height='\" + mycanvas.height + \"' alt='Map' usemap='#immap'><map name='immap' id='immap'><area data-onclick='areaclick=true;' shape='default' nohref alt='' /></map>\";
    };
    myimg.src = awobackup;
    awobackup='';
    //alert('AwobackuP=' + awobackup);
    document.getElementById('sfilter').value='';
    document.getElementById('redoopt').style.display='none';
    } //else {
    //alert('why?');
    //}
    }

    “; ?>
    … working with HTML for the Image Filtering dropdown new visibility controlled option element …
    <?php echo ”

    <option style=display:none; id=redoopt value=redo>Undo Last ...</option>

    “; ?>
    … as well as …
  • stage 2 potential multiple click “rubber banding” event logic below linked to onmousemove or ontouchdown events …
    <?php echo ”

    var relevant=false;

    function lineDistance(x, y, x0, y0) { // thanks to https://codepen.io/daveboling/pen/jWOorz
    return Math.sqrt((x -= x0) * x + (y -= y0) * y);
    }

    function ourDrawLine(myxs1, myys1) { // thanks to https://codepen.io/daveboling/pen/jWOorz
    var xs0=0, ys1=0;
    if (relevant && xs.length > 0) {
    if (xs.length > 1) { return ''; }
    if (xs.length > 1) {
    if (xs[0] > xs[1]) {
    xs0=xs[0];
    ys0=ys[0];
    myxs1=xs[1];
    myys1=ys[1];
    } else {
    xs0=xs[1];
    ys0=ys[1];
    myxs1=xs[0];
    myys1=ys[0];
    }
    } else if (xs[0] > myxs1) {
    xs0=myxs1;
    ys0=myys1;
    myxs1=xs[0];
    myys1=ys[0];
    } else {
    xs0=xs[0];
    ys0=ys[0];
    }
    var zangle = Math.atan2(myys1 - ys0, myxs1 - xs0) * 180 / Math.PI;
    var zdistance = lineDistance(xs0, ys0, myxs1, myys1);
    if (eval('' + zdistance) >= 40) {
    var xs1=xs0 + Math.sin(eval(zangle + 90.0) / (180 / Math.PI)) * zdistance;
    var ys1=ys0 + Math.cos(eval(zangle + 90.0) / (180 / Math.PI)) * zdistance;
    var trf='';
    trf+=' translate(' + eval((xs1 - xs0) / 2) + 'px,' + eval((ys0 - ys1) / 2) + 'px) ';
    console.log('(x,y)=(' + xs0 + ',' + ys0 + ') bearing=' + eval(zangle + 90.0) + ' and angle=' + zangle + ' and distance=' + zdistance + ' trf=' + trf + ' left=' + eval(xs0 - eval((myxs1 - xs0) / 2)) + 'px');
    document.getElementById('rubberband').innerHTML='<hr id=myhr style=z-index:300;background-color:transparent;background-color:rgba(255,0,0,0.5);width:' + zdistance + 'px;></hr><div id=drect></div>';
    document.getElementById('myhr').style.position='absolute';
    document.getElementById('myhr').style.zIndex='300';
    document.getElementById('myhr').style.margin='0 0 0 0';
    document.getElementById('myhr').style.padding='0 0 0 0';
    //document.getElementById('myhr').style.opacity='0.5';
    document.getElementById('myhr').style.left='' + eval(xs0 - eval(Math.abs(myxs1 - xs0) / 2)) + 'px';
    //document.getElementById('myhr').style.left='' + xs0 + 'px';
    document.getElementById('myhr').style.top='' + ys0 + 'px';
    document.getElementById('myhr').style.transformOrigin='' + xs0 + 'px ' + ys0 + 'px';
    document.getElementById('myhr').style.transform='rotate(' + eval(360.0 + zangle) + 'deg)'; // + trf;
    //document.getElementById('myhr').style.backgroundColor='transparent';
    document.getElementById('rubberband').style.backgroundColor='transparent';
    document.getElementById('myhr').style.marginLeft='' + eval(xs0 - document.getElementById('myhr').getBoundingClientRect().left) + 'px';
    if (ys0 < myys1) {
    document.getElementById('myhr').style.marginTop='' + eval(ys0 - document.getElementById('myhr').getBoundingClientRect().top) + 'px';
    } else {
    document.getElementById('myhr').style.marginTop='' + eval(myys1 - document.getElementById('myhr').getBoundingClientRect().top) + 'px';
    }
    document.getElementById('myhr').style.borderBottom='1px dashed green';
    document.getElementById('myhr').title='Click again for further line and rectangle and annotation and text options';
    document.getElementById('rubberband').style.zIndex='300';

    document.getElementById('drect').style.position='absolute';
    document.getElementById('drect').style.zIndex='300';
    document.getElementById('drect').style.margin='0 0 0 0';
    document.getElementById('drect').style.padding='0 0 0 0';
    document.getElementById('drect').style.opacity='0.5';
    document.getElementById('drect').style.left='' + Math.min(xs0,myxs1) + 'px';
    document.getElementById('drect').style.top='' + Math.min(ys0,myys1) + 'px';
    document.getElementById('drect').style.width='' + Math.abs(xs0 - myxs1) + 'px';
    document.getElementById('drect').style.height='' + Math.abs(ys0 - myys1) + 'px';
    document.getElementById('drect').style.backgroundColor='transparent';
    document.getElementById('drect').style.border='1px dotted green';
    document.getElementById('drect').title='Click again for further line and rectangle and annotation and text options';
    console.log(document.getElementById('rubberband').outerHTML + ' ' + document.getElementById('myhr').getBoundingClientRect().left + ' ' + document.getElementById('myhr').getBoundingClientRect().top);
    }
    } else {
    relevant=false;
    document.getElementById('rubberband').innerHTML='';
    }
    }

    “; ?>
    … working with new HTML div element …
    <?php echo ”

    <div id=rubberband></div>

    “; ?>
    … helping (albeit better for non-mobile) that Line and Rectangle functionality be shown to be available should the user venture even a little off their first click positions during stage 2 processing … and lastly …
  • improved Annotations Menu access via a new Emoji ✍ button …
    <?php echo ”

    <button id=bannotations title='Annotations Menu defaults to Scribble Mode for Signatures' onclick=annoit(this);>&#9997;</button>

    “; ?>

… in our changed pdfimageplustext.php Image and Text PDF creator PHP web application.

Previous relevant PDF Image and Text Nodes Image Transformations Tutorial is shown below.

PDF Image and Text Nodes Image Transformations Tutorial

PDF Image and Text Nodes Image Transformations Tutorial

We think under the umbrella term “Image Filtering” of yesterday’s PDF Image and Text Nodes Image Filtering Tutorial PHP GD Image Manipulation functionality, let’s start including …

  • “Image Transformation” such as Scaling (already discussed and implemented with PDF Image and Text Nodes Canvas Scaling Tutorial, way below) …
  • “Image Transformations” such as Flip and Flip Horizontal and Flip Vertical … handled via PHP as per …
    <?php echo ”

    function ourImageFlip($imgsrc, $mode) { // thanks to https://stackoverflow.com/questions/10001728/how-to-flip-image-horizontaly-and-vertically-with-php
    $width = imagesx ( $imgsrc );
    $height = imagesy ( $imgsrc );

    $src_x = 0;
    $src_y = 0;
    $src_width = $width;
    $src_height = $height;

    switch ($mode) {
    case '1': //vertical
    $src_y = $height -1;
    $src_height = -$height;
    break;

    case '2': //horizontal
    $src_x = $width -1;
    $src_width = -$width;
    break;

    case '3': //both
    $src_x = $width -1;
    $src_y = $height -1;
    $src_width = -$width;
    $src_height = -$height;
    break;

    default:
    return $imgsrc;
    break;
    }

    $imgdest = imagecreatetruecolor ( $width, $height );

    if ( imagecopyresampled ( $imgdest, $imgsrc, 0, 0, $src_x, $src_y , $width, $height, $src_width, $src_height ) ) {
    return $imgdest;
    }

    return $imgsrc;
    }

    “; ?>
  • “Image Transformation” Rotation we will handle via HTML5 canvas element functionality, as per …
    <?php echo ”

    function rotateim(degrees) {

    mycanvas = document.getElementById('canvas');
    ctx = mycanvas.getContext('2d');
    myimg = new Image;
    myimg.onload = function() {
    var ow=myimg.width;
    var oh=myimg.height;


    var angle=degrees*Math.PI/180; // thanks to https://math.stackexchange.com/questions/2790488/how-to-find-the-dimensions-new-points-after-rotating-a-shape below
    var c = Math.cos(angle);
    var s = Math.sin(angle);
    var halfw = 0.5*ow;
    var halfh = 0.5*oh;
    var xdelta = Math.abs(c*halfw) + Math.abs(s*halfh);
    var ydelta = Math.abs(s*halfw) + Math.abs(c*halfh);

    //Let xmin = xmin + halfw - xdelta
    //Let ymin = ymin + halfw - ydelta
    mycanvas.width = 2*xdelta;
    mycanvas.height = 2*ydelta;

    //alert('ow=' + ow + ' and oh=' + oh + ' and new width=' + mycanvas.width + ' and height=' + mycanvas.height);


    mycanvas.style.width='' + eval(mycanvas.width) + 'px';
    mycanvas.style.height='' + eval(mycanvas.height) + 'px';

    // Thanks to https://stackoverflow.com/questions/17411991/html5-canvas-rotate-image below
    ctx.clearRect(0,0,mycanvas.width,mycanvas.height);
    ctx.fillStyle = 'white';
    ctx.fillRect(0,0,mycanvas.width,mycanvas.height);


    // save the unrotated ctx of the canvas so we can restore it later
    // the alternative is to untranslate & unrotate after drawing
    ctx.save();

    // move to the center of the canvas
    ctx.translate(mycanvas.width/2,mycanvas.height/2);

    // rotate the canvas to the specified degrees
    ctx.rotate(degrees*Math.PI/180);

    // draw the image
    // since the ctx is rotated, the image will be rotated also
    ctx.drawImage(myimg,-myimg.width/2,-myimg.height/2);
    //ctx.drawImage(myimg,-mycanvas.width/2,-mycanvas.height/2);

    // we’re done with the rotating so restore the unrotated ctx
    ctx.restore();

    if (document.getElementById('tsiz')) {
    ctx.font = '' + document.getElementById('tsiz').value.trim() + 'px ' + document.getElementById('tfam').value.trim();
    }
    if (document.getElementById('tcol')) {
    ctx.fillStyle='' + document.getElementById('tcol').value.trim();
    }
    //ctx.drawImage(myimg,0,0,ow,oh,0,0,mycanvas.width,mycanvas.height); // Or at whatever offset you like
    //alert(564);
    awonow=mycanvas.toDataURL('image/jpeg');
    sofarso=sofarso.replace(awowatchsofar, awonow);
    awowatchsofar=awonow;
    datauri=awonow;
    if (actualuri == '') { actualuri=datauri; }
    datauris[0]=datauri;
    document.getElementById('slideshow').value=awonow;
    document.body.style.backgroundImage='url(' + awonow + ')';
    if (document.getElementById('inimg')) {
    document.getElementById('inimg').style.width='' + eval(mycanvas.width) + 'px';
    document.getElementById('inimg').style.height='' + eval(mycanvas.height) + 'px';
    document.getElementById('inimg').width=eval(mycanvas.width);
    document.getElementById('inimg').height=eval(mycanvas.height);
    document.getElementById('inimg').src=awonow;
    }
    document.getElementById('dimap').innerHTML=\"<img id=imimg style='z-index:99;visibility:visible;position:absolute;top:0px;left:0px;' src='\" + datauri + \"' width='\" + mycanvas.width + \"' height='\" + mycanvas.height + \"' alt='Map' usemap='#immap'><map name='immap' id='immap'><area data-onclick='areaclick=true;' shape='default' nohref alt='' /></map>\";
    };
    myimg.src = document.getElementById('slideshow').value;

    }

    :; ?>

… in our changed pdfimageplustext.php Image and Text PDF creator PHP web application.

Previous relevant PDF Image and Text Nodes Image Filtering Tutorial is shown below.

PDF Image and Text Nodes Image Filtering Tutorial

PDF Image and Text Nodes Image Filtering Tutorial

Because the recent PDF Image and Text Nodes Canvas Scaling Tutorial‘s PDF Image and Text Nodes PDF Creator web application …

  • is written in PHP …
  • involves images as the backdrop to PDF pages

… there is a great resource available to PHP called the GD and Image Functions, specifically its imagefilter function subset of functionality that could add that missing “pizazz” to your PDF creations.

There are a lot of options here …

… that we supply the arguments for, at least to this point, in this first draft of using it here with our changed pdfimageplustext.php Image and Text PDF creator PHP web application.

Previous relevant PDF Image and Text Nodes Canvas Scaling Tutorial is shown below.

PDF Image and Text Nodes Canvas Scaling Tutorial

PDF Image and Text Nodes Canvas Scaling Tutorial

Yesterday’s PDF Image and Text Nodes Absolute Image URL Tutorial got us to thinking about the idea that the image you select as a backdrop to your PDF A4 Portrait or Landscape page may not suit with the dimensions it has to start with. So what if we add the equivalent of …

  • Zoom In
  • Zoom Out
  • Actual Size

… means by which we can call into play our changed pdfimageplustext.php Image and Text PDF creator PHP web application’s “behind the scenes” canvas element to help out. After all, the canvas element has great functionality for transformations, and to scale an image is a transformation.

Below is relevant new (stage 2 relevant) HTML …


<button title='Zoom In' onclick=zoomin();>+</button>&nbsp;<button title='Zoom Out' onclick=zoomout();>-</button>&nbsp;<button title='Actual Size' onclick=zoomone();>=</button>

… and Javascript …


function zoomin() {
scaleim(eval(curfactor * 1.1));
}

function zoomout() {
scaleim(eval(curfactor / 1.1));
}

function zoomone() {
if (Math.abs(eval(1.0 - eval('' + curfactor))) > 0.0001) {
scaleim(1.0);
}
}

function scaleim(towhat) {

mycanvas = document.getElementById('canvas');
ctx = mycanvas.getContext('2d');
myimg = new Image;
myimg.onload = function() {
var ow=myimg.width;
var oh=myimg.height;
mycanvas.width=eval(myimg.width * towhat / curfactor);
mycanvas.height=eval(myimg.height * towhat / curfactor);
mycanvas.style.width='' + eval(myimg.width * towhat / curfactor) + 'px';
mycanvas.style.height='' + eval(myimg.height * towhat / curfactor) + 'px';
if (document.getElementById('tsiz')) {
ctx.font = '' + document.getElementById('tsiz').value.trim() + 'px ' + document.getElementById('tfam').value.trim();
}
if (document.getElementById('tcol')) {
ctx.fillStyle='' + document.getElementById('tcol').value.trim();
}
ctx.drawImage(myimg,0,0,ow,oh,0,0,mycanvas.width,mycanvas.height); // Or at whatever offset you like
//alert(564);
awonow=mycanvas.toDataURL('image/jpeg');
sofarso=sofarso.replace(awowatchsofar, awonow);
awowatchsofar=awonow;
datauri=awonow;
if (actualuri == '') { actualuri=datauri; }
datauris[0]=datauri;
document.getElementById('slideshow').value=awonow;
document.body.style.backgroundImage='url(' + awonow + ')';
if (document.getElementById('inimg')) {
document.getElementById('inimg').style.width='' + eval(mycanvas.width * towhat / curfactor) + 'px';
document.getElementById('inimg').style.height='' + eval(mycanvas.height * towhat / curfactor) + 'px';
document.getElementById('inimg').width=eval(mycanvas.width * towhat / curfactor);
document.getElementById('inimg').height=eval(mycanvas.height * towhat / curfactor);
document.getElementById('inimg').src=awonow;
}
curfactor=eval('' + towhat);
document.getElementById('dimap').innerHTML=\"<img id=imimg style='z-index:99;visibility:visible;position:absolute;top:0px;left:0px;' src='\" + datauri + \"' width='\" + mycanvas.width + \"' height='\" + mycanvas.height + \"' alt='Map' usemap='#immap'><map name='immap' id='immap'><area data-onclick='areaclick=true;' shape='default' nohref alt='' /></map>\";
};
if (Math.abs(eval(1.0 - eval('' + towhat))) < 0.0001) {
myimg.src = actualuri;
} else {
myimg.src = document.getElementById('slideshow').value;
}

}

… code regarding this useful functionality improvement, today.

Previous relevant PDF Image and Text Nodes Absolute Image URL Tutorial is shown below.

PDF Image and Text Nodes Absolute Image URL Tutorial

PDF Image and Text Nodes Absolute Image URL Tutorial

Regarding yesterday’s PDF Image and Text Nodes Relative URL Integration Tutorial …

Yeh, yeh, yeh!
Relative smellative!
What about Absolute?

Well, true enough, but the user here, must consider plagiarism and content appropriation wrongdoings here, and that is why we leave this idea to late in the piece, and not exactly advertise its use as you use this inhouse PHP web application. As well as the fact that most absolute image URLs will fail if you enter them into the “middle management” textbox you can see in action with today’s animated GIF presentation. Nevertheless, some absolute image URLs can be entered into that textbox and form the backdrop of your PDF creation now with a changed pdfimageplustext.php Image and Text PDF creator PHP web application.

The new PHP to do this uses a call to itself, in an iframe, to …

<?php

if (isset($_GET['aburl'])) {
$imdata=str_replace('+',' ',urldecode($_GET['aburl']));
$jmdata='';
$kmdata='';
if ($imdata != '') {
if (strpos(('~' . $imdata), '~//') !== false) {
$jmdata=file_get_contents('http:' . $imdata);
} else if (strpos(strtolower(('~' . $imdata)), '~https:') !== false) {
$jmdata=file_get_contents('http:' . substr($imdata, 6));
} else {
$jmdata=file_get_contents($imdata);
}
if ($jmdata != '') {
echo '<html><body onload=" parent.document.getElementById(' . "'iurl'" . ').value=' . "'" . $kmdata . "'" . '; "></body></html>';
}
}
exit;
}

?>

Previous relevant PDF Image and Text Nodes Relative URL Integration Tutorial is shown below.

PDF Image and Text Nodes Relative URL Integration Tutorial

PDF Image and Text Nodes Relative URL Integration Tutorial

Progressing with improved integrations, on top of the work of yesterday’s PDF Image and Text Nodes Annotations Tutorial, today, we’re revisiting our Relative URL software integration you can read previous progress regarding, with Image and Text Multiple PDF Relative URL Tutorial.

Then, its integration …

  • just supplied relative URL strings … but today, we integrate by …
  • allowing user to click a found thumbnail image of a found Relative URL (ie. on RJM Programming domain) image as the backdrop to a PDF creation

In order to do this we set up the stage 1 hierarchy …

… involving changed condition specific PHP as per …

<?php

$fps="";
$tb="";
$thash="";
$onebad="youllneverfind" . "this";
$twobad="youllneverfind" . "this";
$threebad="youllneverfind" . "this";
$fourbad="youllneverfind" . "this";
$onebadx="youllneverfind" . "this";
$twobadx="youllneverfind" . "this";
$threebadx="youllneverfind" . "this";
$fourbadx="youllneverfind" . "this";
$fivebad="youllneverfind" . "this";
$sixbad="youllneverfind" . "this";
$onl="";
$oncl="";
$onclg="";
$deforder="<option value='-5'>Preview every change for 5 seconds</option><option value='0'>Do no previewing of changes</option>";
$onclf="";
$previewif="<br><iframe name=preview id=preview style=display:none;></iframe>";

if (isset($_GET['fillps'])) {
$fps='<input type=hidden name=fillps value=y></input>';
$oncl=' onclick=" if (window.parent && parent.document.getElementById(' . "'" . 'spreview' . "'" . ')) { top.document.getElementById(' . "'" . 'iurl' . "'" . ').value=this.getAttribute(' . "'" . 'data-href' . "'" . '); top.document.getElementById(' . "'" . 'slideshow' . "'" . ').value=this.getAttribute(' . "'" . 'data-href' . "'" . '); this.target=' . "'" . 'sspreview' . "'" . '; } else if (window.opener) { window.opener.top.document.getElementById(' . "'" . 'slideshow' . "'" . ').value=this.href; } else { top.document.getElementById(' . "'" . 'slideshow' . "'" . ').value=this.href; } "';
$onclg='fillps=y&';
$tb="target=sspreview\t";
$onebad="href=./";
$twobad="href=./PHP/";
$threebad=">./";
$fourbad=">./PHP/";
$onebadx="href=../";
$twobadx="href=/";
$threebadx=">../";
$fourbadx=">/";
$thash="data-";
$fivebad=$_SERVER['DOCUMENT_ROOT'];
$sixbad="";
$deforder="<option value='0'>Do no previewing of changes</option><option value='-5'>Preview every change for 5 seconds</option>";
$onclf="<input id=fillps name=fillps type=hidden value=y></input>";
if ($onl == '') { $onl=' onload="postxit();"'; }
}

?>

Previous relevant PDF Image and Text Nodes Annotations Tutorial is shown below.

PDF Image and Text Nodes Annotations Tutorial

PDF Image and Text Nodes Annotations Tutorial

Modular software is good, in the sense that …

  • jobs developing the software can be compartmentalized
  • jobs developing the software can involve specalized skills
  • software components do not get too big and unwieldy

… and so when we felt, with yesterday’s PDF Image and Text Nodes and Lines and Rectangles Tutorial …

Lines and Rectangles are good … but …

… “other forms of annotation would be better”! And yes, that’s true, but not if it compromises the efficacy of the existing “PDF Image and Text Nodes (and Lines and Rectangles) Creator” PHP web application. Rather than reinventing an “annotation wheel” we’re turning towards …

… we’ve developed in the past, about which you can read at Emoji Borders and Backgrounds Canvas Annotation Tutorial, regarding functionality to enable “scribble” based canvas signature creation, as well as several discrete click based shape and text and image annotation functionalities, all allowing for opacity control, to aid with overlay ideas. Now that could be useful, we figure. And luckily, we’ve integrated this functionality before, and used a …

  • window.opener look, at the existing inhouse canvas based Annotation Menu web application, for a parent integrator … for which …
  • a canvas element data interchange happens

… and we add to that unchanged “existing inhouse canvas based Annotation Menu web application” arrangement, (setTimeout timer) parent checking …


function awowatch() {
if (awo) {
if (!awo.closed) {
var awonow=awo.document.getElementById('topcanvas').toDataURL('image/jpeg');
if (awowatchsofar != awonow) {
sofarso=sofarso.replace(awowatchsofar, awonow);
awowatchsofar=awonow;
datauri=awonow;
datauris[0]=datauri;
document.getElementById('slideshow').value=awonow;
document.body.style.backgroundImage='url(' + awonow + ')';
if (document.getElementById('inimg')) {
document.getElementById('inimg').src=awonow;
}
mycanvas = document.getElementById('canvas');
ctx = mycanvas.getContext('2d');
myimg = new Image;
myimg.onload = function() {
mycanvas.width=myimg.width;
mycanvas.height=myimg.height;
mycanvas.style.width='' + myimg.width + 'px';
mycanvas.style.height='' + myimg.height + 'px';
ctx.font = '' + document.getElementById('tsiz').value.trim() + 'px ' + document.getElementById('tfam').value.trim();
ctx.fillStyle='' + document.getElementById('tcol').value.trim();
ctx.drawImage(myimg,0,0); // Or at whatever offset you like
//alert(564);
document.getElementById('dimap').innerHTML=\"<img id=imimg style='z-index:99;visibility:visible;position:absolute;top:0px;left:0px;' src='\" + datauri + \"' width='\" + myimg.width + \"' height='\" + myimg.height + \"' alt='Map' usemap='#immap'><map name='immap' id='immap'><area data-onclick='areaclick=true;' shape='default' nohref alt='' /></map>\";
};
myimg.src = document.getElementById('slideshow').value;
console.log('changed ');
}
setTimeout(awowatch, 5000);
console.log('ongoing ' + (awonow + '...............................').substring(0,19));
} else {
awo=null;
console.log('closed');
}
} else {
setTimeout(awowatch, 5000);
console.log('null');
}
}

… of child canvas content, and if changed, reflect the changes in the parent canvas and document.body background image, sort of like we did with the emoji text earlier on (with Image and Text PDF Timesheet Emojis Tutorial), with its changed, sometimes supervisory pdfimageplustext.php Image and Text PDF PHP web application, whose “blurb” in stage 2 now reads …

<?php echo ”

document.getElementById('mybody').title='Click once where text to be placed in resultant PDF or more for Annotations. Can use suffix such as x 5 to repeat value on 4 clicks to follow. With dates go consult https://www.w3schools.com/php/func_date_date_format.asp DATE_ATOM type entries where DATE_ followed by ymd lowercase character correspondence in 2nd part means change just date via ymd means where date_ followed by hms lowercase character correspondence in 2nd part means change time via hms means where uppercase 2nd part preceeded by ymd lowercase character in 1st part means change datetime via ymd means where datE_ followed by hms lowercase character correspondence in 2nd part means change datetime via hms means. Incrementing scale can be done via ++ or -- or +=2 or -=4 types of strings before x 5 repeat definitions. An offset to DATE_ATOM type entry meaning of today & now can be achieved via no spaces between it & offset ++ or -4 type of string & optional more until string such as Tuesday. Basis date is " . $newdts . "';

“; ?>

Did you know?

There are many favoured techniques individual programmers and organizations will have towards software integration.

For us, being so fond of interpretive (you might say, substitutional) approaches, to add to …

  • change hardcodings to parameterized variables … we’d like to add, as exemplified in today’s work …
  • the Javascript popup box escalation from (the kind of dumb, but informative) alert popup box to (the just as informative, but also interactive, and so potentially dynamically useful to the user) prompt popup box usage

… exemplified by the Javascript code snippet …


if (eval('' + xs.length) < 3) { // alert('line');
fans=prompt('Draw a line? ' + String.fromCharCode(10) + String.fromCharCode(10) + 'OK for line ' + String.fromCharCode(10) + 'Cancel for text ' + String.fromCharCode(10) + '+ for Annotations and Signatures Canvas Menu', '');
} else {
if (Math.abs(xs[0] - x) <= 0.000004) { xfilledr=''; // alert('rectangle');
fans=prompt('Draw a rectangle? ' + String.fromCharCode(10) + String.fromCharCode(10) + 'OK for rectangle ' + String.fromCharCode(10) + 'Cancel for text ' + String.fromCharCode(10) + '- for lines ' + String.fromCharCode(10) + '+ for Annotations and Signatures Canvas Menu', '');
} else {
xfilledr='x';
// alert('filled rectangle');
fans=prompt('Infill a rectangle? ' + String.fromCharCode(10) + String.fromCharCode(10) + 'OK for infilled rectangle ' + String.fromCharCode(10) + 'Cancel for text ' + String.fromCharCode(10) + '- for lines ' + String.fromCharCode(10) + '+ for Annotations and Signatures Canvas Menu', '');
}
}

… means by which we can let the user have access to the integrated Canvas Annotation functionality.

Previous relevant PDF Image and Text Nodes and Lines and Rectangles Tutorial is shown below.

PDF Image and Text Nodes and Lines and Rectangles Tutorial

PDF Image and Text Nodes and Lines and Rectangles Tutorial

Onto yesterday’s PDF Image and Text Nodes Mobile Scrolling Tutorial‘s progress we turn our attention back to some Fpdf talents …

  • draw lines into a PDF document … and …
  • draw and/or infill rectangles into a PDF document

… as two ideas heading towards “some annotating talents” for our Image and Text Nodes (and now Lines and Rectangles) PDF creator PHP web application. It was again in that onclick logic a lot of the change was needed …


var xs=[], ys=[];

document.getElementById('mybody').onclick=function(e){
var yes=false;
if (areaclick) {
areaclick=false;
} else {
e = e || window.event;
e.preventDefault();
if (!showingc) {
startrecording=true;
if (e.originalEvent) {
if (e.originalEvent.touches) {
yes=true;
}
}
var rectis=document.body.getBoundingClientRect();
if (e.touches) {
if (e.touches[0].pageX) {
x = e.touches[0].pageX;
y = e.touches[0].pageY;
if (eval('' + xs.length) == 0) {
//alert('0:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
xs.push(x);
ys.push(y);
setTimeout(askaway,4500);
} else if (eval('' + xs.length) >= 2) {
if (eval('' + xs.length) == 2) {
document.title+=' | ';
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs[0]=Math.min(xs[0], xs[1]);
ys[0]=Math.min(ys[0], ys[1]);
xs[1]=xs[2];
ys[1]=ys[2];
x=xs[0];
y=ys[0];
// alert(xs.length + ' ? RE rect');
} else {
x=xs[0];
y=ys[0];
if (eval('' + xs.length) == 4) { xs[0]+=0.00001; }
}
} else {
xs.push(x);
ys.push(y);
x=xs[0];
y=ys[0];
}
} else {
x = eval(-rectis.left + e.touches[0].clientX);
y = eval(-rectis.top + e.touches[0].clientY);
if (eval('' + xs.length) == 0) {
//alert('1:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
xs.push(x);
ys.push(y);
setTimeout(askaway,4500);
} else if (eval('' + xs.length) >= 2) {
if (eval('' + xs.length) == 2) {
document.title+=' | ';
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs[0]=Math.min(xs[0], xs[1]);
ys[0]=Math.min(ys[0], ys[1]);
xs[1]=xs[2];
ys[1]=ys[2];
x=xs[0];
y=ys[0];
// alert(xs.length + ' ? RE rect');
} else {
x=xs[0];
y=ys[0];
if (eval('' + xs.length) == 4) { xs[0]+=0.00001; }
}
} else {
xs.push(x);
ys.push(y);
x=xs[0];
y=ys[0];
}
}
//console.log('pos3=' + pos3 + ',pos4=' + pos4);
} else if (yes) {
if (e.originalEvent.touches[0].pageX) {
x = e.originalEvent.touches[0].pageX;
y = e.originalEvent.touches[0].pageY;
if (eval('' + xs.length) == 0) {
//alert('0:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
xs.push(x);
ys.push(y);
setTimeout(askaway,4500);
} else if (eval('' + xs.length) >= 2) {
if (eval('' + xs.length) == 2) {
document.title+=' | ';
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs[0]=Math.min(xs[0], xs[1]);
ys[0]=Math.min(ys[0], ys[1]);
xs[1]=xs[2];
ys[1]=ys[2];
x=xs[0];
y=ys[0];
// alert(xs.length + ' ? RE rect');
} else {
x=xs[0];
y=ys[0];
if (eval('' + xs.length) == 4) { xs[0]+=0.00001; }
}
} else {
xs.push(x);
ys.push(y);
x=xs[0];
y=ys[0];
}
} else {
x = eval(-rectis.left + e.originalEvent.touches[0].clientX);
y = eval(-rectis.top + e.originalEvent.touches[0].clientY);
if (eval('' + xs.length) == 0) {
//alert('1:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
xs.push(x);
ys.push(y);
setTimeout(askaway,4500);
} else if (eval('' + xs.length) >= 2) {
if (eval('' + xs.length) == 2) {
document.title+=' | ';
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs[0]=Math.min(xs[0], xs[1]);
ys[0]=Math.min(ys[0], ys[1]);
xs[1]=xs[2];
ys[1]=ys[2];
x=xs[0];
y=ys[0];
// alert(xs.length + ' ? RE rect');
} else {
x=xs[0];
y=ys[0];
if (eval('' + xs.length) == 4) { xs[0]+=0.00001; }
}
} else {
xs.push(x);
ys.push(y);
x=xs[0];
y=ys[0];
}
}
//console.log('pos3=' + pos3 + ',pos4=' + pos4);
} else if (e.clientX || e.clientY) {
x = eval(-rectis.left + e.clientX);
y = eval(-rectis.top + e.clientY);
if (eval('' + xs.length) == 0) {
//alert('2:' + rectis.left + ',' + rectis.top);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
xs.push(x);
ys.push(y);
setTimeout(askaway,4500);
} else if (eval('' + xs.length) >= 2) {
if (eval('' + xs.length) == 2) {
document.title+=' | ';
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs[0]=Math.min(xs[0], xs[1]);
ys[0]=Math.min(ys[0], ys[1]);
xs[1]=xs[2];
ys[1]=ys[2];
x=xs[0];
y=ys[0];
// alert(xs.length + ' ? RE rect');
} else {
x=xs[0];
y=ys[0];
if (eval('' + xs.length) == 4) { xs[0]+=0.00001; }
}
} else {
xs.push(x);
ys.push(y);
x=xs[0];
y=ys[0];
}
} else {
x = e.pageX;
y = e.pageY;
if (eval('' + xs.length) == 0) {
//alert('3:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
xs.push(x);
ys.push(y);
setTimeout(askaway,4500);
} else if (eval('' + xs.length) >= 2) {
if (eval('' + xs.length) == 2) {
document.title+=' | ';
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs.push(Math.abs(xs[0] - xs[1]));
ys.push(Math.abs(ys[0] - ys[1]));
xs[0]=Math.min(xs[0], xs[1]);
ys[0]=Math.min(ys[0], ys[1]);
xs[1]=xs[2];
ys[1]=ys[2];
x=xs[0];
y=ys[0];
// alert(xs.length + ' ? RE rect');
} else {
x=xs[0];
y=ys[0];
if (eval('' + xs.length) == 4) { xs[0]+=0.00001; }
}
} else {
xs.push(x);
ys.push(y);
x=xs[0];
y=ys[0];
}
}
}
}
};

… allowing the user four extra seconds after that first click, now, to …

  • add in one more line end click
  • add in two more clicks for a drawn rectangle extending to the first two click positions
  • add in three or more clicks for a filled in rectangle extending to the first two click positions

… in its changed, sometimes supervisory pdfimageplustext.php Image and Text PDF PHP web application.

Previous relevant PDF Image and Text Nodes Mobile Scrolling Tutorial is shown below.

PDF Image and Text Nodes Mobile Scrolling Tutorial

PDF Image and Text Nodes Mobile Scrolling Tutorial

With yesterday’s PDF Image and Text Nodes Windows Tutorial it is time, today, to fix a …

  • mobile device issue in usage …
  • when browsing for files …
  • and using the “Take Photo” option, perhaps …
  • obtaining an image far bigger than the screen …
  • the user scrolls to text node positions

… we start accounting for that scrolling, as per the Javascript changes to document.body onclick event logic …


document.getElementById('mybody').onclick=function(e){
var yes=false;
if (areaclick) {
areaclick=false;
} else {
e = e || window.event;
e.preventDefault();
if (!showingc) {
startrecording=true;
if (e.originalEvent) {
if (e.originalEvent.touches) {
yes=true;
}
}
var rectis=document.body.getBoundingClientRect();
if (e.touches) {
if (e.touches[0].pageX) {
x = e.touches[0].pageX;
y = e.touches[0].pageY;
//alert('0:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
setTimeout(askaway,500);
} else {
x = eval(-rectis.left + e.touches[0].clientX);
y = eval(-rectis.top + e.touches[0].clientY);
//alert('1:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
setTimeout(askaway,500);
}
//console.log('pos3=' + pos3 + ',pos4=' + pos4);
} else if (yes) {
if (e.originalEvent.touches[0].pageX) {
x = e.originalEvent.touches[0].pageX;
y = e.originalEvent.touches[0].pageY;
//alert('0:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
setTimeout(askaway,500);
} else {
x = eval(-rectis.left + e.originalEvent.touches[0].clientX);
y = eval(-rectis.top + e.originalEvent.touches[0].clientY);
//alert('1:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
setTimeout(askaway,500);
}
//console.log('pos3=' + pos3 + ',pos4=' + pos4);
} else if (e.clientX || e.clientY) {
x = eval(-rectis.left + e.clientX);
y = eval(-rectis.top + e.clientY);
//alert('2:' + rectis.left + ',' + rectis.top);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
setTimeout(askaway,500);
} else {
x = e.pageX;
y = e.pageY;
//alert('3:' + document.body.offsetLeft + ',' + document.body.offsetTop);
document.getElementById('blob').innerHTML+='<div class=dblob onmouseover=\" blobover(this); \" onmouseout=\" blobout(this);\" onclick=\" blobdel(this.id); \" title=\"\" id=\"bpdftext' + coordn + '\" style=\"position:absolute;left:' + eval(0 + x) + 'px;top:' + eval(0 + y) + 'px;background-color:red;z-index:100;\">x</div>';
document.getElementById('immap').innerHTML+=\"<area id=area\" + areacnt + \" alt='\" + cidurls + \"' shape=rect onclick=ack(this.alt,\" + coordn + \",true); coords='\" + eval(-8 + x) + \",\" + eval(-8 + y) + \",\" + eval(8 + x) + \",\" + eval(8 + y) + \"' nohref />\";
areacnt++;
setTimeout(askaway,500);
}
}
}
};

… in its changed, sometimes supervisory pdfimageplustext.php Image and Text PDF PHP web application.

Previous relevant PDF Image and Text Nodes Windows Tutorial is shown below.

PDF Image and Text Nodes Windows Tutorial

PDF Image and Text Nodes Windows Tutorial

It’s instructive adding “platforms” to the list of “underlying operating system” functionalities, and though it can be a slow slog, the work you put in now, can help future endeavours. And so, onto the recent Web Share API PDF Book Creation Notifications Tutorial we learnt in adding “Windows” as an “underlying operating system” …

  • you cannot chain PHP exec commands with semicolon …
  • we needed to install Ghostscript for PDF conversion purposes …
  • we needed to remind ourselves that, of course, as far as downloads go, you’ll need to download Fpdf … ours being version version 1.7 and install it to MAMP Document Root folder “MarkItUp/fpdf17″ (or MarkItUp\fpdf17 for Windows) …
  • we needed to incorporate DIRECTORY_SEPARATOR operating system file references where we’d hardcoded “/” previously …

… and more reliably, converting to videos, you succeed more often on these local web server environments first converting to …

  • ffmpeg inhouse *.ts format … and then onto …
  • more publicly accessible *.webm format

… and we coded some other “hardcodings become parameterized” matters via …

<?php

$convertcommand="C:\\PROGRA~1\\IMAGEM~1.0-Q\\";
$ffmpegcommand="C:\\PROGRA~1\\IMAGEM~1.0-Q\\";

$mvstr="mv ";
$cpstr="cp ";
$portstr=":8888";

if (PHP_OS =='WINNT' || PHP_OS =='WIN32' || PHP_OS =='Windows') {
$cpstr="copy ";
$mvstr="rename ";
$portstr="";
$convertcommand.="magick.exe ";
if (file_exists($ffmpegcommand . "ffmpeg.exe")) {
$ffmpegcommand.="ffmpeg.exe ";
} else {
$ffmpegcommand="";
}
} else {
if (file_exists("/usr/local/bin/ffmpeg")) {
$ffmpegcommand="/usr/local/bin/ffmpeg ";
} else if (file_exists("/usr/bin/ffmpeg")) {
$ffmpegcommand="/usr/bin/ffmpeg ";
} else {
$ffmpegcommand="";
}
if (file_exists("/usr/local/cpanel/3rdparty/bin/convert")) {
$convertcommand="/usr/local/cpanel/3rdparty/bin/convert ";
} else if (file_exists("/usr/local/bin/convert")) {
$convertcommand="/usr/local/bin/convert ";
} else if (file_exists("/usr/bin/convert")) {
$convertcommand="/usr/bin/convert ";
}
}

?>

… based on personal experience installing MAMP and ImageMagick and ffmpeg and Fpdf and GhostScript here on this Windows laptop, with its changed, sometimes supervisory pdfimageplustext.php Image and Text PDF PHP web application (we’d now like you to download to MAMP Document Root folder).

Previous relevant Web Share API PDF Book Creation Notifications Tutorial is shown below.

Web Share API PDF Book Creation Notifications Tutorial

Web Share API PDF Book Creation Notifications Tutorial

Today we’re shoring up the recent Web Share API Intranet Video Tutorial‘s …

… as well as loosening our reliance on ImageMagick “convert” command when converting a set of Jpegs to a PDF Book (and animated GIF), where we are finding it unable to allocate enough memory, on occasions. Instead we pivot back to Fpdf to backup ImageMagick, should it run into trouble with the PDF Book conversion.

And regarding the animated GIF conversion, regarding this ImageMagick subject, it would be great for “Intranet” functionality purposes, to install it on your local device.

Given this, and all the other installing and downloading advice, on your “Intranet” environment, you can now end up with a window showing links to content, or content itself, for …


PDF (Book) -> Animated GIF -> Video

… as you can see with today’s tutorial picture for the changed HTML and Javascript web_share_api_test.html Web Share API supervisor web application (we’d now like you to download to MAMP Document Root and HTMLCSS subfolder, as well as client_browsing.htm Client Browsing supervisor) to start making this a possibility, with its changed, sometimes supervisory pdfimageplustext.php Image and Text PDF PHP web application (we’d now like you to download to MAMP Document Root folder).

Also changed (and good to download into MAMP local Apache/PHP/MySql web server Document Root “PHP/animegif” folder), today, is the changed tutorial_to_animated_gif.php our inhouse Animated GIF Creator helper PHP web application.

If you have created any PDF Books, we have relied on user common sense as to when they try to view that (now Fpdf compiled) PDF made up of a set of individual PDF slide Jpegs (themselves compiled via ImageMagick). To improve that we link to Notifications API interfacing …

<?php

$notifif='';

function wildout($wild, $out) {
global $outputpdf, $notifif, $sizeofdatauris;
$fgo=0;

$inorder=true;
foreach (glob($wild) as $filename) {
pdfaddpage($filename);
if (sizeof(explode('-', $filename)) == 2) {
if (explode('.',('' . explode('-', $filename)[1]))[0] != ('' . $fgo)) { file_put_contents('bad8.bad8', $fgo . ' ... ' . $filename); $inorder=false; }
} else {
file_put_contents('bad7.bad7', $filename);
}
$fgo++;
}

if (($inorder || ('' . $fgo) >= ('' . $sizeofdatauris)) && $fgo != 0) {
file_put_contents('bad9.bad9', 'here ' . $fgo);
if (('' . $fgo) > ('' . $sizeofdatauris)) {
$notifif=' onload=" if (1 == 1) { window.open(' . "'" . 'https://www.rjmprogramming.com.au/HTMLCSS/notifications_ideas.php?scheduledblurb=' . urlencode('PDF Book nearing readiness for sharing now ' . ' ... ' . $fgo . ' of ' . $sizeofdatauris . ' complete') . "'" . ',' . "'notifif','top=50,left=50,width=50,height=50'" . '); } else { window.opener.document.getElementById(' . "'notifif'" . ').src=' . "'" . 'https://www.rjmprogramming.com.au/HTMLCSS/notifications_ideas.php?scheduledblurb=' . urlencode('PDF Book ready for sharing now ...') . "'" . '; } "';
} else {
$notifif=' onload=" if (1 == 1) { window.open(' . "'" . 'https://www.rjmprogramming.com.au/HTMLCSS/notifications_ideas.php?scheduledblurb=' . urlencode('PDF Book ready for sharing now ...') . "'" . ',' . "'notifif','top=50,left=50,width=50,height=50'" . '); } else { window.opener.document.getElementById(' . "'notifif'" . ').src=' . "'" . 'https://www.rjmprogramming.com.au/HTMLCSS/notifications_ideas.php?scheduledblurb=' . urlencode('PDF Book ready for sharing now ...') . "'" . '; } "';
}
}


if ($out != "") {
if (file_exists($out)) { unlink($out); }
$outputpdf->Output($out, "F");
if (file_exists('bad2.bad2') && strpos($_SERVER['SERVER_NAME'], 'rjmprogramming.com.au') !== false) {
if (('' . ourfilesize('bad2.bad2')) != '1' && ('' . ourfilesize('bad2.bad2')) != '2') {
file_put_contents('bad3.bad3', $wild . ' ... ' . $out . ' .;. ' . file_get_contents('bad2.bad2'));
file_put_contents('bad2.bad2', ' ');
}
}
}
}

?>

Previous relevant Web Share API Intranet Video Tutorial is shown below.

Web Share API Intranet Video Tutorial

Web Share API Intranet Video Tutorial

Adding to yesterday’s Web Share API Animated GIF Tutorial …

  • animated GIF (PDF sharing) … today we add …
  • video (via animated GIF via PDF)

… but we need you to think “Intranet” for our first idea here. Here at our macOS setup we use a MAMP local Apache/PHP/MySql web server as our “Intranet” portal.

We’ve also installed the great ffmpeg on this macOS system, and thanks to some great advice from this link about ffmpeg lossless conversion of animated GIF to video …


ffmpeg -i video.gif -c:v libx264 -preset veryslow -qp 0 output.mp4

… we have a tweaked HTML and Javascript web_share_api_test.html Web Share API supervisor web application (we’d now like you to download to MAMP Document Root HTMLCSS folder, as well as client_browsing.htm Client Browsing supervisor) to start making this a possibility, with its changed, sometimes supervisory pdfimageplustext.php Image and Text PDF PHP web application (we’d now like you to download to MAMP Document Root folder).

Local web servers will not only have this extra accessible functionality, but their response times should be faster too. The public RJM Programming version will understand a MAMP HTTP://localhost:888/ clone and also look for ffmpeg to facilitate our “Intranet” feeling video creation solution.

Previous relevant Web Share API Animated GIF Tutorial is shown below.

Web Share API Animated GIF Tutorial

Web Share API Animated GIF Tutorial

On top of yesterday’s Web Share API Download Tutorial work, there are some more advances we’ll like to integrate into our inhouse Web Share API interfacer.

The first of these is to offer an animated GIF file conversion when a PDF (so far just those Books) is the media being shared. When thinking of approaches to encapture image presentation material in a single file when we think of PDF we also often think of animated GIF, as it has the additional advantage of being able to be, in a webpage …

  • an HTML img element … or …
  • an HTML element’s background image

… both offering that image rotation and looping advantages that animated GIF have over PDF, as again the data fidelity and viewing incarnation advantages PDF has over animated GIF. We just needed …


function doit(tv) {
document.getElementById('aag').href=document.getElementById('aag').href.split('&')[0] + '&delay=' + tv;
}


function basebit(inuis) {
if (inuis.indexOf('//') != -1) {
if (inuis.split('//')[1].indexOf('/') != -1) {
return inuis.replace(inuis.split('//')[0] + '//' + inuis.split('//')[1].split('/')[0] + '/','');
}
}
return inuis;
}

function trythis(inpdfidea) {
if (inpdfidea.toLowerCase().indexOf('-0.pdf') != -1) {
woq=window.open(inpdfidea.split('#')[0], '_blank', 'top=50,left=50,width=800,height=800');
document.getElementById('adown').innerHTML+='&nbsp;<a style="text-decoration:none;cursor:pointer;background-color:yellow;border:2px solid red;margin: 13px 13px 13px 13px;" target=_blank title="Download ' + ('/' + inpdfidea.split('#')[0]).split('/')[eval(-1 + ('/' + inpdfidea.split('#')[0]).split('/').length)] + ' PDF Book" href="' + inpdfidea.split('#')[0] + '" download>' + '&nbsp;Download <font size=1>' + ('/' + inpdfidea.split('#')[0]).split('/')[eval(-1 + ('/' + inpdfidea.split('#')[0]).split('/').length)] + '</font> PDF Book&nbsp;</a>&nbsp;<a style="text-decoration:none;cursor:pointer;background-color:pink;border:2px solid blue;margin: 13px 13px 13px 13px;" target=_blank title="Create ' + ('/' + inpdfidea.split('#')[0]).split('/')[eval(-1 + ('/' + inpdfidea.split('#')[0]).split('/').length)].replace('-0.pdf','-ag.gif') + ' Animated GIF" href="/pdfimageplustext.php?first=' + encodeURIComponent(basebit(inpdfidea).split('#')[0].replace('-0.pdf','-0.jpg')) + '&delay=500' + '" id=aag>' + '&nbsp;Create <font size=1>' + ('/' + inpdfidea.split('#')[0]).split('/')[eval(-1 + ('/' + inpdfidea.split('#')[0]).split('/').length)].replace('-0.pdf','-ag.gif') + '</font> Animated GIF Delay &nbsp;</a>&nbsp;<input onchange=doit(this.value); type=number style=display:inline-block;background-color:pink; value=500 min=1 step=1 id=iag></input>';
}
return inpdfidea;
}

… in the changed HTML and Javascript web_share_api_test.html Web Share API supervisor web application to start making this a possibility, with its changed, sometimes supervisory pdfimageplustext.php Image and Text PDF PHP web application.

Previous relevant Web Share API Primer Tutorial is shown below.

Web Share API Primer Tutorial

Web Share API Primer Tutorial

The web is improved by operating system Context Menus via right clicks or two finger gestures over …

  • links
  • media
  • document

… webpage contents. Today, we roadtest a web API called “Web Share API” that simulates right clicks or two finger gestures with your normal everyday button press on a webpage.

Of most use, is the “Web Share API” which can take multiple selected files (via a “browse” type button) …


// Thanks to https://developer.mozilla.org/en-US/docs/Web/API/Navigator/share

document.getElementById('share').addEventListener('click', async () => {
const files = input.files

if (files.length === 0) {
shareurl();
output.textContent = 'No files selected.'
return
}

// feature detecting navigator.canShare() also implies
// the same for the navigator.share()
if (!navigator.canShare) {
output.textContent = `Your browser doesn't support the Web Share API.`
return
}

if (navigator.canShare({ files })) {
try {
await navigator.share({
files,
title: 'Media or documents',
text: 'Take a look at media or documents below' + String.fromCharCode(10) + String.fromCharCode(10)
})
output.textContent = 'Shared!'
} catch (error) {
output.textContent = `Error: ${error.message}`
}
} else {
output.textContent = `Your system doesn't support sharing these files.`
}
});

… and attach them to an email or SMS or some other “Sharing Application” on that operating system “Context Menu” in readiness for the user to fill in other requirements and then send off to the recipient, as required.

This API was a little strange to us in that on this macOS setup Safari web browser worked, rather than Google Chrome, which is a turn around from our usual expectations with these experimental Javascript APIs. Feel free to try our “proof of concept” “Web Share API” based, thanks, HTML and Javascript web application you can also try below …

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

If this was interesting you may be interested in this too.

This entry was posted in Animation, eLearning, Event-Driven Programming, Operating System, Tutorials and tagged , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , . Bookmark the permalink.

Leave a Reply

Your email address will not be published. Required fields are marked *

You may use these HTML tags and attributes: <a href="" title=""> <abbr title=""> <acronym title=""> <b> <blockquote cite=""> <cite> <code> <del datetime=""> <em> <i> <q cite=""> <strike> <strong>
